Latest portable hardness tester technology. Utilizes both ultrasonic and dynamic type portable hardness testers in one unit. Can test non-destructive and handle small or thin work parts down to 2mm of thickness, as well as testing large parts. Extremely versatile, with many options and configurations to handle all types of hardness tester applications.

Phase II PHT-6080 Offers

Extremely versatile, with many options and configurations to handle all types of hardness tester applications.

Features

• Best for smooth bearing type surfaces
• Non-Destructive hand held portable hardness tester
• Combines UCI and Leeb portable hardness testing in one state of the art device
• Test steel with min thickness of .08" and unlimited max thickness (Other materials may have larger minimum thickness levels, depending on hardness)
• Blazing fast test results
• Rockwell, Brinell and Vickers hardness test conversions shown on display
• Large Memory w/USB Output
• Choice of manual UCI probes; 1kg, 2kg, 5kg & 10kg
• Optional Motorized Probes: .30kg, .80kg, & 1kgf
• Available Impact Devices(Leeb) D, DC, D+15, G & DL

Applications

• Electrical/Mechanical Inspection
• Test & Measurement
• Manufacturing
